Imax Power Smart Low-Voltage Hybrid Cabinet: Enabling Safe and Efficient New Energy Grid Integration

Driven by “dual carbon” goals, new energy installations surge. Achieving safe grid integration, efficient management, and stable power supply for multi-energy complementary systems is critical. Imax Power’s smart low-voltage hybrid cabinet leverages “functional integration, professional protection, and adaptive flexibility” to deliver end-to-end solutions for PV, wind, and other new energy systems, redefining value standards for low-voltage grid-tied equipment.

I. Technical Core: Multi-Functional Integrated “Smart Hub”

Imax Power’s cabinet achieves deep integration of AC confluence, bidirectional metering, and grid-switching functions via modular design and intelligent algorithms. Its technical principles unfold in three tiers:

1. AC Confluence Layer

• Multi-channel AC confluence modules support current integration from PV inverters, wind turbines, and energy storage systems, reducing line losses and equipment footprint.
  Example: In a 10MW PV plant, Imax Power’s cabinet reduces DC cable usage by 30%, boosting system efficiency by 2%.

2. Bidirectional Metering Layer

• High-precision energy meters enable bidirectional power measurement (error <0.5%), providing data for peak-shaving optimization and energy trading.

3. Intelligent Control Layer

• DSP-based digital signal processors monitor voltage, frequency, and harmonics in real-time, automatically adjusting grid-tied strategies to comply with IEEE 1547 and other international standards.

II. Product Strengths: Six Advantages of an All-Round Solution

1. Comprehensive Function Integration, Doubled Space Efficiency

• Combines AC confluence, bidirectional metering, reactive compensation, and protection in one unit. Replaces traditional multi-cabinet setups, reducing footprint by 50%. Ideal for space-constrained rooftop PV and industrial parks.

2. Stable Power Supply, Reliable Load Support

• Dual-power switching design ensures seamless transfer to backup power (e.g., energy storage systems) within 0.1 seconds during mains failures. Annual availability exceeds 99.99% for critical loads like hospitals and data centers.

3. Premium Components, Robust Reliability

• Core components (circuit breakers, contactors, sensors) sourced from Schneider, ABB, and Siemens pass 100,000+ mechanical endurance tests and operate in -40°C~+70°C environments.

4. Superior Protection, Harsh Environment Adaptability

• IP55-rated enclosure with dust/water resistance withstands sandstorms, heavy rain, and extreme temperatures. In Gansu’s desert PV project, the cabinet endured 12 typhoon-level sandstorms with zero failures.

5. Multi-Layer Safety Defenses

• Integrates overcurrent, overvoltage, undervoltage, and leakage protection. Arc-fault protection and rapid grounding switches ensure response times <10ms.

6. Broad New Energy Compatibility

• Supports PV, wind, storage, and diesel generators. Adaptive algorithms smooth power fluctuations caused by intermittent renewable generation.

III. Applications: From Industrial Parks to Microgrids

1. Industrial-Commercial Distributed PV

• For a car factory in Jiangsu, the cabinet’s “8-in-1” confluence design boosted self-consumption by 40%, saving >¥2 million annually in electricity costs.

2. New Energy Microgrids

• In Hainan’s island microgrid project, seamless switching between PV/wind and storage achieved 99.9% reliability, displacing diesel generation and reducing CO₂ by 1,200 tons/year.

3. PV-Storage-Charging Integrated Stations

• At a Beijing fast-charging station, dynamic adjustment of PV-storage output stabilized the grid. Total Harmonic Distortion (THD) dropped from 8% to 3%, extending equipment lifespan by 30%.

IV. Customization: User-Centric Flexibility

Imax Power offers full-spectrum customization:

• Appearance: Material/color options for industrial or tech-aesthetic needs.
• Power: 50kW–2MW modular designs for residential, commercial, or utility-scale use.
• Communication: Protocol compatibility (Modbus, Profinet, OPC UA) for seamless SCADA integration.

V. Technical Specifications

Battery Parameters

• Rated Voltage: Main circuit 400V; Auxiliary circuit AC 230V
• Insulation Voltage: Main circuit 690V/1000V
• Power Factor Adjustment: 0.95 (lag) to 0.95 (lead), auto-compensation

Structural Parameters

• Protection: IP55
• Enclosure: Cold-rolled steel with anti-corrosion coating
• Cooling: Natural convection
• Partition: 1/2/3/4 compartments meeting arc-flash resistance (≥65kA/0.3s)

Monitoring & Compliance

• Measurement: Voltage/current (0.5-grade accuracy), active/reactive energy, THD (≤5%)
• Protocol: MODBUS TCP, 4G wireless
• Standards: IEC61641-V3, IEC61439

Environmental Adaptability

• Operating Temperature: -5°C~+40°C (24h avg ≤35°C)
• Humidity: ≤95% (non-condensing)
• Altitude: ≤2000m

VI. Innovation-Driven, Building a Green Energy Future

Imax Power’s smart hybrid cabinet embodies “integration, intelligence, and safety,” resolving efficiency and security challenges in new energy grid integration. From desert PV plants to coastal microgrids, it serves as an “invisible guardian” of energy flow. Imax Power will continue pioneering innovations to advance global green energy adoption.
