| Operating Voltage | Three-phase four-wire 380VAC±10% without neutral |
| Rated Output Voltage | 1500V |
| Rated Output Current | 0~200A |
| Output Voltage Range | 0VDC~1500VDC |
| Output Ripple RMS | <±1% FS (20%~100% rated current) |
| Input Undervoltage/Overvoltage | 330 (±5) V / 450 (±5) V |
| Communication Bus Protocol | RS485/Modbus |
| Operating Temperature | -15~45℃ |
| Dimensions (H×W×D) | 600mm×600mm×2000mm×2 (Two modules stacked) |
The IM48-6KA series high-frequency switching rectifier module is an AC-DC module with adjustable AC voltage input and DC voltage output. The module features high power density, high power factor, low harmonics and high efficiency, and has the performance of allowing multiple modules to be paralleled.
Product Features:
Product Specification Parameters:
| Category | Parameter | Details |
|---|---|---|
| Input Characteristics | Operating Voltage | Three-phase four-wire 380VAC±10% without neutral |
| Frequency | 60Hz | |
| Input Current | <500A | |
| Output Characteristics | Rated Output Voltage | 1500V |
| Rated Output Current | 0~200A | |
| Output Voltage Range | 0VDC~1500VDC | |
| Output Voltage Display Accuracy | 1V | |
| Operating Mode | Constant Voltage, Constant Current | |
| Output Current Display Accuracy | 0.1A | |
| Maximum Efficiency | >94% max | |
| Voltage Regulation Accuracy | <±2%FS (20%~100% rated output voltage/current) <无要求> (<20% rated output voltage/current) |
|
| Current Regulation Accuracy | <±2%FS (20%~100% rated output current) | |
| Temperature Coefficient | <0.05%/℃ | |
| Current Sharing Imbalance | / | |
| Output Ripple RMS | <±1% FS (20%~100% rated current) | |
| Efficiency | >94% peak | |
| Dielectric Withstanding Voltage | 2K Vac 50Hz/1min, Input-Output/Input-Ground/Output-Ground | |
| Protection Features | Input Undervoltage/Overvoltage | 330 (±5) V / 450 (±5) V |
| Input Phase Loss | Yes | |
| Output Overvoltage Protection | 1530V | |
| Output Current Limiting | 205A | |
| Short Circuit Protection | Yes | |
| Overcurrent Protection | Yes | |
| Overtemperature Protection | Heatsink temperature >70℃, module shutdown protection | |
| Communication & Alarm | Communication Bus Protocol | RS485/Modbus |
| Alarm & Status | Mains overvoltage/undervoltage, output overcurrent/overvoltage/short circuit/overtemperature, communication abnormalities, etc. | |
| Physical Characteristics | Application Scenario | Indoor use only |
| Operating Temperature | -15~45℃ | |
| Cooling Method | Intelligent Air Cooling <65dB | |
| Dimensions (H×W×D) | 600mm×600mm×2000mm×2 (Two modules stacked) |
